Resolution 0.1℃ DP Trace Moisture Analyzer Repeatability +/-0.5℃ DP

Product Categories

Beijing york instrument

Contact Now

Name: Resolution 01 DP Trace Moisture Analyzer Repeatability 05 DP
Brand: PhyMetrix
Price: 1 USD

Brand Name : PhyMetrix

Model Number : DPT-600Plus

Place of Origin : CHINA

MOQ : 1

Payment Terms : T/T

Delivery Time : 1-2weeks

name : trace moisture analyser

Accuracy : Temperature Compensated

Resolution : 0.1℃ DP

Range : -110℃ -+20℃ DP

Repeatability : +/-0.5℃ DP

Operating Temp : -20℃ to +60 ℃

Products : Trace Moisture Monitor

Fast Responding : 5 Mins

Contact Now

Resolution 0.1℃ DP , Trace Moisture Analyzer , Repeatability +/-0.5℃ DP

Technical Specifications

Performance		Operating Conditions
Measurement Ranges	-110℃ -+20℃ DP -60℃-+20℃ DP	Operating Humidity	Less than 95%(Non-Condensing)
Resolution	0.1℃ DP	Operating Temp	-20℃ to +60 ℃
Response Time	95% of step change in 5 mins	Inlet Gas Pressure	150psig
Repeatability	+/-0.5℃ DP	Flow Rate	>1 LPM

Electrial Specifications		Mechanical Specifications
Display	2.5”LCD,320*240 Screen Resolution	Protection	Intnsically Safe,Class 1,Div 1 Group B,C,D
Battery	Li-ion rechargeable,8 hours on full charge	Dimensions	Height:5.51” Width:5.04” Depth:8.42”
Input Charge Voltage	115/230VAC	Weight	2.6KG

Resolution 0.1℃ DP Trace Moisture Analyzer Repeatability +/-0.5℃ DP

Advantages

·Reproducible over a wide measurement range -110°Cdp to +20°Cdp

·Fast response

·Temperature compensated

·NIST traceable calibration

·Easy to use software

·Ergonomic & convenient housing
